The pancake load cell LCP02 offers a reliable and versatile solution for measuring both static and dynamic forces in traction (tension) and compression directions. This shear web load cell is constructed from durable stainless steel, ensuring long-lasting performance and resilience in demanding environments. The LCP02 is designed for easy installation onto solid, flat surfaces using 3xM4 screws through its 4.5mm through holes, positioned strategically around the transducer. At the center, an M8x1.25 tapped hole provides compatibility with various loading attachments, such as load buttons, eye bolts, and other accessories, offering adaptability for different testing setups.

The Miniature Single Point Load Cell LCE04 is a highly efficient and precise weight transducer, designed to meet the needs of applications where space constraints and cost-effectiveness are primary concerns. With its compact size, lightweight construction, and low power consumption, the LCE04 is an ideal choice for weighing applications in confined spaces that require accurate measurements without exceeding budgetary limits. The load cell is available in rated capacities of 1kg, 2kg, 5kg, and 10kg, and boasts an impressive 0.05% non-linearity of the full scale, ensuring consistent and reliable readings.

The parallelogram load cell LSM300 is engineered from lightweight aluminum, making it an excellent choice for applications in medical devices, robotics, and OEM solutions. Its innovative design features two side holes for mounting and a center hole for loading, allowing for easy integration into various systems, even in space-constrained environments. The slim body of the LSM300 enhances its suitability for applications requiring compact and efficient force measurement solutions.

The digital indicator SD01 is a high-precision device designed to deliver 0.01% accuracy through its robust aluminum housing and advanced 24-bit Sigma-Delta ADC. Compatible with a wide range of strain gauge type load cells, force sensors, and torque transducers, it supports unamplified mV/V output for both 4-wire and 6-wire configurations with rated outputs between 0.5mV/V and 3.0mV/V. This versatility makes the SD01 ideal for various force and torque measurement applications.

The Hollow Pancake Load Cell LCP05 is a versatile force measurement solution designed with a central threaded hole and four evenly distributed mounting holes on the bottom for secure installation. When the load mechanism passes through the sensor, the LCP05 functions as a washer load cell, measuring compression force exclusively. However, when the load structure is connected to the central threaded hole, it measures both compression and traction forces, adding flexibility to its application.

The Single Ended Beam Load Cell LCG06 is an advanced force sensor designed to provide high-precision weighing with stability and durability across various applications. This load cell is temperature compensated, ensuring accurate and consistent results even when operating in environments with fluctuating temperatures. The LCG06 is engineered to feature excellent resistance to side forces, which enhances its reliability in demanding industrial settings where lateral forces may otherwise compromise performance.

The Micro Load Cell Sensor LCE05 is specifically engineered for weighing applications where limited mounting space is a constraint, yet accurate measurements are essential, all while staying within a tight budget. This miniature load cell is available in rated capacities of 300g, 500g, 750g, and 1000g, providing versatility for a range of precision measurement needs. Built on proven strain gauge technology, the LCE05 delivers high accuracy with an impressive 0.05% non-linearity of the full scale, ensuring reliable performance for demanding applications.

The miniature flange-to-flange reaction torque load cell RTT11 is a compact, precision-engineered device ideal for a variety of OEM applications. It features a 14.7mm diameter through-hole running through the center of the transducer, allowing for seamless integration into systems where space is limited. This design ensures that the sensor can be installed effortlessly into existing equipment, making it suitable for applications that require high accuracy in tight spaces.

The Miniature Jr. S-beam load cell LCS07 is a compact, precision-engineered force sensor constructed from durable stainless steel and based on proven strain gauge technology. Designed for both tension and compression force measurements, the LCS07 is ideally suited for applications where mounting space is tight and limited. Its robust design ensures accurate and reliable performance, making it a top choice for engineers and industry professionals.

The Low Profile Button Load Cell LCB04 is a compact, high-performance sensor specifically designed for compression force measurement in restricted spaces. With an ultra-low profile of only 5mm in height, the LCB04 is among the thinnest load cells available, making it ideal for applications with limited axial space. Its design includes four threaded holes around the sensor, simplifying mounting on a flat surface for quick and secure installation. This feature ensures the load cell remains stable under load, reducing installation time and enhancing ease of use in industrial and laboratory environments.

The Low Profile Tension Compression Load Cell LRF350 is a high-precision force sensor constructed from durable stainless steel, ensuring reliability and longevity in demanding applications. Featuring an M12 tapped hole on each side, the LRF350 can be easily mounted to various test setups and machinery, providing seamless integration into existing systems. Available in rated capacities of 50kg, 100kg, 200kg, 300kg, 500kg, and 1000kg, this model is versatile enough to meet a wide range of force measurement needs.

The flange-to-flange reaction torque sensor RTT04 is a high-precision, stainless steel torque transducer engineered for both clockwise and anticlockwise loading. This robust sensor is available in rated capacities of 20Nm, 30Nm, 50Nm, 100Nm, 150Nm, and 200Nm, making it versatile enough for a range of torque measurement applications. Built on reliable strain gauge technology, the RTT04 achieves an impressive less than 0.2% full scale non-linearity, ensuring high accuracy and consistency in data collection.

The tension-compression load cell SLCB is a durable, high-precision sensor constructed from stainless steel, ideal for measuring forces in both tension (pull) and compression (push) directions. With rated capacities of 50kg, 100kg, 200kg, 500kg, 1000kg, 2000kg, and 5000kg, this load cell is suitable for various industrial and testing applications requiring reliable and accurate force measurements.

The hollow type low profile load cell LCP06 is expertly engineered with a central tapped hole for straightforward application of loads and three evenly distributed counterbores that enable secure fastening to a solid base. This thoughtful design ensures that the transducer remains stable during force measurement, providing reliable and repeatable results. Constructed from rugged alloy steel, the LCP06 boasts a mechanically robust design that withstands demanding conditions, making it an excellent choice for axial dynamic force measurement.
